Zhejiang Bioclean Machinery Technology Co., Ltd
|
| Brand Name: | Bioclean |
| Model Number: | ZBJ5120GXWBEV |
| MOQ: | 1 Piece |
| Price: | 4980-5995usd |
| Payment Terms: | T/T |
| Supply Ability: | 5,000 units per year |
Weight: 11800Kg, strong for all suction work.
Size: 7310×2340×2860mm, fits various workplaces.
Power: 217hp electric, strong, eco-friendly, efficient.
Load: 3845Kg, carries much dirt, fewer trips.
Battery: Lithium iron phosphate (Shanwei BYD), stable range.
Motor: Permanent magnet (Jingjin Electric), 95kW rated/160kW peak, strong, responsive.
Protection: Aluminum side (bolted); Q345B rear (bolted, 120×60mm, 410mm off ground).
Brakes: CM4XL-4S/4M ABS (Guangzhou Ruili), stable, safe.
Options
| Item | ZBJ5120GXWBEV |
| Energy type | Pure Electric |
| Dimension(L x W x H) | 7310×2340×2860(mm) |
| Chassis | BYD112014FBEVD1 |
| Engine | TZ365XSC07 |
| Curb Weight | 7760(Kg) |
| Rated Loading | 3845(Kg) |
| Total Mass | 11800(Kg) |
| Maximum Speed | 95(km/h) |
| App./Dep.Angle | 19/13(°) |
| Front / Rear suspension | 1205/1905(mm) |
| Axle Load | 3900/7900kg |
| Tank Volume | 5040L |
| Optional Configurations |
Intelligent Monitoring System |
| Multilingual Control Panel | |
| Anti-Overflow Alarm Device | |
| Quick-Connect Fittings & Multi-Size Suction Hoses | |
| Hydraulic Drive System | |
| Self-Cleaning Flushing System | |
| Overload Protection Device | |
| Anti-overflow Valve | |
|
Anti-UV Thermal Insulation Coating |
| High-Efficiency Cooling System | |
| Moisture-Resistant Electrical Components | |
| Corrosion-Resistant Sealing Gaskets | |
| High-Flow Cooling Water Pump | |
|
Tank Thermal Insulation Layer |
| Engine Preheating System | |
| Battery Heater | |
| Anti-Freeze Vacuum Pump Oil | |
| Suction Hose Heating Tape | |
| Low-Temperature-Resistant Rubber Parts | |
| Drain Valve Heat Tracing System |
