| Brand Name: | Bioclean |
| Model Number: | ZBJ5160GXWE6 |
| MOQ: | 1 Piece |
| Price: | 6275-7855usd |
| Payment Terms: | T/T |
| Supply Ability: | 5,000 units per year |
Total Weight: 16200Kg, stable for suction, transport and discharge of fecal liquid or dirt.
Size: 7350,7480,7550×2500,2550×3300,3350,3450,3550mm, fits various work environments.
Power: 239hp, strong for efficient operations.
Load Capacity: 8270,8205,8070,8005Kg, handles large fecal liquid or dirt amounts.
Wheelbase: Only 3950mm.
Tank Capacity: Total 10.5m³; effective 10m³.
Tank Dimensions: Straight section 4150×1800mm (diameter); total length 4870mm.
ABS: Optional J ABS (Jiaozuo Borui Ke) and ABS/ASR-24V-4S/4M (Xiangyang Dongfeng Longcheng), ensuring stable braking.
Protection: Side/rear (Q235). Side: bolted; rear: welded (150×50mm section, 470mm off ground).
Direct power ETC, speed limiter (89km/h).
Cab (with chassis).
Positions/styles of urea tank, gas tank, battery, pump (left/right sides).
Hydraulic locking rod, rear outlet, and appearance styles.
| Item | ZBJ5160GXWE6 |
| Energy type | Diesel |
| Dimension(L x W x H) | 7350,7480,7550×2500,2550×3300,3350,3450,3550(mm) |
| Chassis | EQ1165LJ9CDE |
| Engine | D4.5NS6B240 |
| Curb Weight | 7800,8000(Kg) |
| Rated Loading | 8270,8205,8070,8005(Kg) |
| Total Mass | 16200(Kg) |
| Maximum Speed | 89,105(km/h) |
| App./Dep.Angle | 19/11,19/12,19/13(°) |
| Front / Rear suspension | 1260/2140,1260/2270,1260/2340,1420/1980,1420/2110,1420/2180,1450/1950,1450/2080,1450/2150(mm) |
| Axle Load | 5600/10600kg |
| Tank Volume | 10000L |
| Optional Configurations |
Intelligent Monitoring System |
| Multilingual Control Panel | |
| Anti-Overflow Alarm Device | |
| Quick-Connect Fittings & Multi-Size Suction Hoses | |
| Hydraulic Drive System | |
| Self-Cleaning Flushing System | |
| Overload Protection Device | |
| Anti-overflow Valve | |
|
Anti-UV Thermal Insulation Coating |
| High-Efficiency Cooling System | |
| Moisture-Resistant Electrical Components | |
| Corrosion-Resistant Sealing Gaskets | |
| High-Flow Cooling Water Pump | |
|
Tank Thermal Insulation Layer |
| Engine Preheating System | |
| Battery Heater | |
| Anti-Freeze Vacuum Pump Oil | |
| Suction Hose Heating Tape | |
| Low-Temperature-Resistant Rubber Parts | |
| Drain Valve Heat Tracing System |
