Zhejiang Bioclean Machinery Technology Co., Ltd
|
| Brand Name: | Biotec |
| Model Number: | ZBJ5310ZXXZZBEV |
| MOQ: | 1 Piece |
| Price: | 5165-7685usd |
| Payment Terms: | T/T |
| Supply Ability: | 5,000 units per year |
Total Weight: 31000Kg, stable for garbage collection and transfer.
Size: 9360×2520×3200mm, fits urban and suburban scenarios.
Power: 489hp, strong for efficient garbage handling.
Load Capacity: 15620Kg, carries large garbage amounts.
Battery: Lithium iron phosphate (cells and assemblies from CATL and China Innovation Aviation).
Motor: Permanent magnet synchronous (TZ400XS035, CRRC Times), 250kW rated/360kW peak power.
ABS: ABS-E 4S/4M (ZF Shanghai), ensuring stable braking.
Protection: Side (aluminum alloy, bolted); rear lower (Q235A, bolted, 120×120mm, 480mm off ground).
Equipped with satellite positioning recorder.
Direct power ETC.
Chassis options: cab decals, front mask/lights, monitoring systems, fenders, pedals, logos, wheel hubs, protection styles, camera
appearance, etc.; also various upper assembly layouts and devices.
| Item | ZBJ5310ZXXZZBEV |
| Type of energy | Pure electric |
| Dimension(L x W x H) | 9360×2520×3200(mm) |
| Chassis | ZZ1312V3567Z13BEV |
| Engine | TZ400XS035 |
| Power | 489ps |
| Curb Weight | 15250(Kg) |
| Rated Loading | 15620(Kg) |
| Total Mass | 31000(Kg) |
| Max.Speed | 89(km/h) |
| App./dep. Angle | 17/22(°) |
| Front/Rear Overhang | 1500/1185(mm) |
| Axle Loading | 6500/7000/17500 (tandem axle group) |
|
Cleaning works fast
We are a professional factory making special trucks. We have many types. We can make them as you need. |
|
The box can hold a lot.
Its outside is curved and smooth. The bottom plate is folded without welding, so it won’t leak. It looks clean and nice. It’s hard to deform, very strong, and holds more than other similar products.
|
|
|
|
