Hanging Barrel Garbage Pickup Truck 1360kg Load Capacity 10 Bin

Hanging Barrel Garbage Pickup Truck 1360kg Load Capacity 10 Bin

Brand Name:	Bioclean
Model Number:	ZBJ5030CTYC
MOQ:	1 Piece
Price:	5685-7355 usd
Payment Terms:	T/T
Supply Ability:	5,000 units per year

Detail Information

Product Description

Detail Information

Place of Origin:

Ningbo, China

Certification:

CE/ISO 9001/EPA/UL/SASO/ECAS/ Certification

Dimension(L X W X H):

4715×1600×1945mm

Chassis:

SC1031XND64A

Engine:

DAM16KR/DK15C

Weight:

1350kg

Load Capacity:

1360kg

Chassis Total Capacity:

2840kg

Maximum Speed:

100km/h

Approaching/Departure Angle:

40°/15°

Front/Rear Overhang:

720mm/1295mm

Axle Load:

1290kg/1550kg

Carriage Volume:

10 Standard 240L Trash Cans

Packaging Details:

Wooden Case /Iron Frame/Container/SKD /CKD

Supply Ability:

5,000 units per year

Highlight:

Garbage Pickup Truck 1360kg

High Capacity Garbage Pickup Truck

10 Bin trash pick up truck

Product Description

Hanging Barrel Garbage Can Truck Open Type High Capacity Mini Garbage Truck

Gross Weight: 2840kg

Loading Capacity: 1360kg

Usage: Collects and transports barreled garbage via dustbin, lifting tailgate and hydraulic devices.

Curb Weight: Includes fire extinguisher, on-board tools, etc., excluding spare tire.

Cargo Bed & Rails:

Standard rail weight: 255.3kg; Optional rail-free weight: 247.9kg.

Main material: Q235.

Thickness: Bottom plate and rear side plates 2mm; front plate and main side plates 1.5mm.

Optional cargo bed rails: Height 600mm (with rails); 360mm (without rails).

Tailgate: Horizontal length in stowed state: 200mm; Weight: 195kg.

Engine & Fuel Consumption: Equipped with DK15C and DAM16KR engines. Fuel consumption: 7.5L/100km.

ABS System: Model YF8; Control mode: Four-channel.

Optional Configurations:

Front fog lights (not optional with chassis).

Rim styles (optional with chassis).

Square fuel tank (optional with chassis).

ETC on-board device.

parameters

Item	ZBJ5030CTYC
Energy Type	Gasoline (92#)
Dimension	4905x1600x1945mm
Carriage Internal Dim.	2650x1480x360mm
Chassis	SC1031XND64A
Engine	DAM16KR/DK15C
Curb Weight	1470 kg
Rated Loading	1240 kg
Total Mass	2840 kg
Max.Speed	100 km/h
App./Dep.Angle	40°/15°
Front/Rear Overhang	720/1485 kg
Axle Load	1290/1550 kg
Rear Hyd.Tailboard	Rated load 500kg,capable of loading 10,standard 240Ltrash cans
